Field of application: YHZS25 mobile concrete mixing plant is a mobile concrete mixing station equipment. Through ingenious design, the mixing station's batching system, weighing system, mixing host, storage, unloading and automatic control system.
The mobile concrete mixing plant is a mobile concrete mixing station equipment. Through ingenious design, the batching system, batching system, mixing system, storage, unloading, and automatic control system of the mixing station are centralized in a trailer unit, and the movement of the mixing station is realized through the trailer. YHZS25 type mobile concrete mixing plant can produce 25-square-concrete concrete output. It has the advantages of flexible movement, quick and easy assembly and disassembly, and stable performance. It is the preferred choice for field construction projects such as railways, highways, ports, bridges, and hydropower projects. model. Jianxin YHZS mobile mixer is a highly integrated mobile concrete mixing plant. The main machine adopts a forced twin-shaft mixer, which has the characteristics of short stirring time, rapid discharge, even mixing, high productivity, and can produce plastic, dry hard and other concrete, reliable quality. Aggregate is measured by electronic weigher or measured separately. The cement, water, and additives are weighed and weighed. The measurement is accurate, and the microcomputer is centralized to control. The operation is simple, easy to adjust, and reliable. The aggregate uses bucket lifting or belt feeding. Siemens devices are used for electrical components, which have reliable performance and high production power. They are suitable for on-site mass production of concrete. The abradant liner and agitator blades are specially treated with wear resistant materials. The unique shaft end support and seal type greatly increase the service life of the main machine. The station is fully functional and has a complete composition of ingredients, mixing, metering, and control systems. It has a small footprint and high cost performance. It is suitable for the construction of small and medium-sized hydropower projects, highways, ports, airports, and bridges.
YHZS75 Mobile concrete mixing plant
Korea YHZS50 Mobile concrete mixing plant
Shanxi YHZS50 Mobile concrete mixing plant
Taiwan YHZS50 Mobile concrete mixing plant
Taiwan YHZS60 Mobile concrete mixing plant
Changchun YHZS50 Mobile concrete mixing plant
YHZS25 mobile concrete mixing plant mixing host uses JS500 concrete mixer.500 concrete mixer mixing system consists of motor, pulley, reducer, open gear, mixing drum stirring device, oil supply device and other components. During operation, the motor drives the secondary gear reducer. The two shafts of the reducer drive the two horizontal agitating shafts to reverse at the same speed through the two pairs of open gears.
YHZS25 mobile concrete mixing plant uses PLD800 concrete batching machine, which consists of feeding mechanism, weighing system and electrical control system. The characteristic is that the feeders are arranged in the shape of the playing card plum 1 and fed by the belt conveyor. The weighing method is a lever plus a single sensor, and the measurement is accurate.
YHZS25 mobile concrete mixing plant belt conveyor is an ideal high-efficiency continuous transportation equipment. It has the advantages of long conveying distance, large volume and continuous conveying, and it is reliable in operation, easy to realize automation and centralized control, and it is very convenient to disassemble.
The YHZS25 mobile concrete mixing station belt conveying frame is a truss structural member connecting the main chassis and the aggregate ingredient frame, and the belt frame is built in; the main frame, the belt frame and the batching frame are integrated to form the main structure of the entire mobile mixing station.
Bolted cement silo
The bolted type cement silo of YHZS25 concrete mixing plant is designed and produced for the difficulties of packing and packing of cement silo, difficulty in on-site cylinder making, difficulty in transfer of construction site, and super high and super wide transportation. Cement silos (cement tanks) are in line with industry standards.
The Integral-type cement silo of YHZS25 concrete mixing plant is a one-piece cement silo with a large volume. The cargo itself is super long and super high, suitable for near-distance transportation. 200 tons ,300 tons of cement silo is required to be produced on site.
The horizontal cement silo of YHZS25 concrete mixing plant has a cylindrical structure, and the bottom is supported by four round tube legs. The whole silo is in the form of steel structure and welded; the top is equipped with a dust collector and pressure relief valve. The horizontal cement silo meets the industry standard. The warehouse body is made of steel plate and grooved hoop, and the legs are welded by national standard pipe.
The screw conveyor of YHZS25 concrete mixing plant is not only used in concrete mixing plant (floor), asphalt mixing plant, dry mortar production line to transport cement, fly ash, mineral powder, dry sand, etc., but also widely used chemical, building materials, grain, metallurgy, electric power and other industries transporting powdery, small granular materials. However, this device is not suitable for conveying bulky, compressive, bonded or easy-to-knot materials.
