Jianxin HZS180 lenvironmental concrete mixing station configuration details

HZS180 series concrete mixing plant equipment is a complete set of mechanical equipment that is composed of a plurality of unit modules, with automatic mixing production and assembly line production. Its working components mainly include mixing machine, batching machine, belt conveyor, weighing system, water supply system, material storage system, electrical control system, etc. Since the dust pollution is controlled during the production process, it is necessary to set up an environmentally friendly concrete mixing plant. Dust removal system.



The mixing machine model is JS3000 double-shaft forced mixer. It can stir sandstone aggregate with a maximum diameter of 80mm, and the discharge capacity is 3000L. It can complete the production task of 180 cubic meters per hour of concrete with other equipment in the mixing station. The control system is concentrated in a special control room, equipped with a professional console and control computer. The operator can control and operate the entire production process of the whole set of equipment in the control room, and can always know the operation status of each part of the equipment. In this way, the whole set of equipment has the advantages of simplicity, high efficiency and environmental protection. Therefore, the HZS180 environmentally-friendly concrete mixing station has become the mainstream equipment used by domestic large-scale commercial mixing stations.
